NKA 160505 – 5V / 0.5A SMPS Adapter
Ultra-Compact 5V Solution for Low-Power Electronic Devices
The NKA 160505 is a single-output, 5V / 0.5A AC-DC switching adapter designed with advanced high-frequency technology. Operating across an impressively wide input range of 100–300 V AC, this compact and efficient adapter ensures stable DC power for small telecom equipment, IoT devices, and other low-power applications. Its natural convection cooling and wall-mountable design allow for easy installation in space-constrained environments.
Key Specifications
Voltage: 230 Vac (Nominal)
Voltage Range: 100–300 Vac
Frequency: 50 Hz (48–52 Hz range)
Efficiency: ~80% (at full load)
Voltage: 5V (4.5–5.5 V adjustable range)
Current: 0.5A
Ripple & Noise: Max 50 mV / Max 2 mV*
Over Voltage: 6.1 V (fold-back type protection)
Output Overload: Folds back, resumes on fault removal
Short Circuit: Automatic recovery (Hiccup mode)
Over Temperature: Shuts down until temperature normalizes
DC Output Cable: ~1.5 m
Dimensions: 75 × 52 × 34 mm (W × H × D)
Mounting: 2/3 Pin Wall Mountable
DC Jack: 2.1/5.5 or Micro USB (model-dependent)
(Ripple/Noise measured with standard capacitive load. Always consult the datasheet for exact conditions.)
Product Highlights & Benefits
Compact Design: Easily fits into tight installations while maintaining airflow for natural convection cooling.
Wider Input Voltage: Operates effectively from 100–300 V AC for universal suitability.
SMPS Based: High-frequency switching ensures better efficiency and lower heat output.
Robust Protections: Overload, short-circuit, and over-temperature features keep devices safe.
User-Friendly Mounting: Simple wall-mount form factor reduces clutter.
High-frequency switching design reduces size and improves power density.
Stable 5V DC output for sensitive electronic applications.
Overload: Output folds back, automatically resumes upon load correction.
Short Circuit: Hiccup mode to prevent damage; normal operation returns once short is cleared.
Thermal Shutdown: Proactively stops operation if internal temperature rises too high.
Operating Temp: 0–50 °C, Storage Temp: 0–70 °C
Humidity: 5–95% RH (non-condensing)
Enclosure: Rugged plastic housing with flame-retardant rating (UL94 V-0 if applicable).
Safety, EMI & EMC: Designed to meet IEC 60950 and CISPR22 / IEC61000 for EMC.
Insulation: 1.5 kVac isolation between input & output.
Low-power telecom or network terminals
Small IoT or sensor devices needing 5V / 0.5A
Consumer electronics accessories and basic lighting controls
